Dehydration Lubricating Oil Purifier Oil Filtration Oil Purifier For Lubrication Oil
Machine Types:
TF Vacuum Turbine Oil Purifier
TF-E Explosion-proof Turbine Oil Purifier
TF-A Automatic Control Vacuum Turbine Oil Purifier
TF-Z Coalescence and Separation Turbine oil Purifier
TC Turbine Oil Vacuum Purifier and Centrifugal Combination Plant
NSH-TF-E Explosion-Proof Turbine Oil Purifier
Sino-NSH-TF-E is Explosion-proof type designed for flammable and combustible working conditions in power plant, petroleum, petrochemical, chemistry, coal mining, metallurgy and other industries.
Sino-NSH-TF-E adds an explosion-proof system compare to NSH-TF, using comprehensive explosion-proof technology. The components such as heating system, electric control system, motor and solenoid valves etc are well-selected Explosion-proof type adapt to different danger level.
Technical data
| Parameter | Value |
| TF-150 | TF-300 |
| Capacity, liters/hour | 9000 | 18000 |
| Heating Power, kW | 72 | 120 |
| Total Power, kW | 78 | 129 |
| Power Supply | Fully customizable |
| Inlet Diameter, mm | 40 | 65 |
| Outlet Diameter, mm | 40 | 65 |
Dimensions
(without trailer) | length, mm | 1850 | 2400 |
| width, mm | 1250 | 1700 |
| height, mm | 1610 | 1760 |
| Weight (without trailer), kg | 750 | 1500 |
| Processed Oil Spec | Water Content, ppm | ≤ 100 |
| Cleanliness (NAS 1638) | ≤ 6 |
| Filtration Fineness, um | ≤ 5 (or 1-5 as needed) |
| Emulsification value, min | ≤ 15 |
Welcome to email to sinonsh315@sino-purification.com to learn more detailed technical information.
