35kw Degassing Vacuum Lubrication Oil Purifier 1800L/H

Brand Name : SINO-NSH

Model Number : LV-30

Certification : CE, ISO,SGS, SASO, SONCAP

Place of Origin : China

MOQ : 1 Set

Price : Negotiate

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50 sets per month

Delivery Time : 15 working days

Packaging Details : Wooden Case

Total Power : 35kW

Capacity : 1800L/H

Color : Custom

Power Supply : Fully Customizable

Material : Stainless Steel/Carbon Steel

Warranty : 1years

After Warranty Service : Video Technical Support, Online Support

Product Name : Double-Stage Vacuum Transformer Oil Purifier

Contact Now

Mine Industry Explosion-Proof 35kw Degassing Vacuum Lubrication Oil Purifier

Other Optional Models for Transformer Oil/Insulation Oil:


VFD series-- Double-Stage Vacuum Transformer Oil Purifier Machine
VFD-R series-- Double-Stage Vacuum Black Insulation Oil Regeneration Machine

VF series-- Single-Stage Vacuum Transformer oil Filtration machine.

Vacuum Lubrication Oil Purifier Description:

1. Sino-NSH-LV is a dehydration and degassing unit with thermal and vacuum processing. It is a multifuncational purifier which can treat various kinds of lubricant oils.
2. Sino-NSH-LV is mainly used to remove dissolved and fee water,and particulate impurities effectively so as to increase special indexes of lubricant oil. Combining with vacuum system, the multi-stage filtration system adopts a high dehydration efficiency,it has a strong anti-emulsifying capability, which could separate the large amount of water from oil and trace water from oil. The clearness of final oil can be under 6 NAS and water can be under 100PPM after processing with our machine.
3. Sino-NSH-LV maintains an optimized structure and safe controls so as to meet comprehensive requirements of transformer manufacturers and service companies.

35kw Degassing Vacuum Lubrication Oil Purifier 1800L/H

Vacuum Lubrication Oil Purifier Technical Parameters:

Parameter Value
LV-10 LV-20 LV-30 LV-50 LV-100 LV-150 LV-200
Capacity, liters/hour 600 1200 1800 3000 6000 9000 12000
Heating Power, kW 15 18 30 45 90 120 180
Total Power, kW 17 21 35 50 96 126 186
Power supply Fully Customizable
Inlet Diameter, mm 20 20 20 25 40 50 65
Outlet Diameter, mm 20 20 20 25 40 50 65
Dimensions
(without trailer)		 length, mm 1350 1500 1550 1900 2200 2400 2900
width, mm 1100 1200 1250 1400 1500 1600 1800
height, mm 1700 1750 1800 1800 1850 1900 2000
Weight(without trailer), kg 600 800 900 1150 1500 1700 2400
Processed Oil Spec Water Content, ppm ≤100
Dielectric Strength, Kv ≤6
Filtration Fineness, um ≤5( or 1-5 as needed )

Other Models Purifier Machines

TF Series:
TF series oil filter is a filtration and dehydration unit with thermal and vacuum processing,it's ideal for filtration and dehydration of turbine oil, this unit can extend turbine oil life by removing contaminates from oil, such as water, gas and particulates, improve the oil properties.
FV Series:
LV series oil filter is a stainless steel machine with thermal and vacuum processing, it's mainly used to improve the properties of phosphate ester fire-resistent oil in generator set.
GER Series:
Used oil regeneration system is suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil, and used hydraulic oil, other used lubrication oil of machinery.
GED series:
it is used to recycle all kinds of waste oil into base oil or diesel oil with high quality.

35kw Degassing Vacuum Lubrication Oil Purifier 1800L/H

35kw Degassing Vacuum Lubrication Oil Purifier 1800L/H


Product Tags:

35kw Degassing Lubrication Oil Purifier



Vacuum Lubrication Oil Purifier 1800L/H



Double Stage Transformer Oil Purifier


Quality 35kw Degassing Vacuum Lubrication Oil Purifier 1800L/H wholesale

35kw Degassing Vacuum Lubrication Oil Purifier 1800L/H Images
